OptiXstar XGS-PON Wi-Fi 7 ONT
Shipping calculated at checkout.
Huawei OptiXstar EN8145B7Ns is an XGS-PON and Wi-Fi 7 routing-type ONT. It uses the XGS-PON and Wi-Fi 7 technologies to implement ultra-broadband access, high performance and wide coverage for users. The high forwarding performance ensures the user experience of voice and data services, and provides customers with an ideal all-optical access solution and future-oriented service support capability.
It provides one 2.5GE port, three GE ports, one POTS port, one USB port and 2.4GHz&5GHz Wi-Fi 7 .
| Parameters | OptiXstar EN8145B7Ns |
| NNI | XGS-PON |
| UNI | 1x2.5GE+3xGE+1xPOTS+1xUSB2.0+2.4G Hz&5 GHz Wi-Fi 7 |
| Optical connector | SC/APC |
| Dimensions (H x W x D) (without external antenna and pads) |
157 mm x 250 mm x 30 mm (excluding the base) |
| Weight | About 543 g (excluding the base) |
| Operating temperature | 0°C to 40°C |
| Operating humidity | 5% RH to 95% RH (noncondensing) |
| Power adapter input | 100–240 V AC, 50/60 Hz |
| System power supply | 12 V DC, 1.5 A |
| Static power consumption | 6.6 W |
| Maximum power consumption | 18 W |
| XGS-PON port | • Class N1/N2 • Receiver sensitivity: -28 dBm • Wavelengths: 1260–1280 nm upstream, 1575–1580 nm downstream • Upstream and downstream rate: 9.953 Gbit/s upstream, 9.953 Gbit/s downstream • Wavelength blocking filter (WBF) • Flexible mapping between GEM Port and TCONT • SN/Password/SN+Password/Bi-directional authentication based on OMCI • Upstream and downstream FEC • SR-DBA and NSR-DBA |
| Ethernet port | • Ethernet port-based VLAN tags and tag removal • 1:1 VLAN, N:1 VLAN, or VLAN transparent transmission • QinQ VLAN • Limitation on the number of learned MAC addresses • MAC address learning • GE port supports 10 Mbit/s, 100 Mbit/s and 1000 Mbit/s auto-adaptation • 2.5GE port supports 10 Mbit/s, 100 Mbit/s, 1000 Mbit/s and 2500 Mbit/s auto-adaptation |
| Wi-Fi | • IEEE 802.11 b/g/n/ax/be (2.4 GHz) • IEEE 802.11 a/n/ac/ax/be (5 GHz) • 2×2 MIMO (2.4 GHz&5 GHz) • Antenna gain: 5 dBi • WMM (Wi-Fi Multi Media) • Air interface rate: 688 Mbit/s(2.4 GHz); 2882 Mbit/s(5 GHz) • 4096 QAM • 160 MHz frequency bandwidth • WPA3/WPA2/WPA1 • WPS • Multiple SSIDs • MU-MIMO • MLO (Multi-Link Operation) • Multi-RU |
Next generation Wi-Fi 7 technology
▪ IEEE 802.11 b/g/n/ax/be (2.4 GHz)
▪ IEEE 802.11 a/n/ac/ax/be (5 GHz)
▪ 2×2 MIMO (2.4 GHz&5 GHz)
▪ Air interface rate: 688 Mbit/s(2.4 GHz); 2882 Mbit/s(5 GHz)
▪ 4096 QAM,160 MHz frequency bandwidth
Smart service
▪ Scheduled Wi-Fi shutdown
▪ Smart Wi-Fi sharing:
Portal/802.1x authentication
SoftGRE-based sharing
https://e.huawei.com/en/products/optical-terminal/en8145b7ns
